CSB电池 GP12340

局数 6
电压值 12 V
安培数 34 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
重量(kg)  Approx. 10.48kg. (23.10 lbs.)
最大放电电流5秒(A)  380A (5sec.)
内阻(mΩ)  Approx. 8.0 mΩ
温度工作范围  Discharge：-15℃~50℃(5°F~122°F)
Charge：-15℃~40℃(5°F~104°F)
Storage：-15℃~40℃(5°F~104°F)
一般使用温度工作范围  25°C ± 3°C (77°F± 5°F)
浮充使用充电条件  13.5 to 13.8 VDC/unit Average at 25°C (77°F)
安培数/只  10.2A
循环寿命测试条件  14.4 to 15.0 VDC/unit Average at 25°C (77°F)
单一放电条件  CSB Batteries can be stored for more than 6 months at 25°C (77°F) Please charge batteries before using. For higher temperatures the time interval will be shorter.
端子  B5-L terminal to accept M5 nut & bolt
电槽组材质  ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request.
